Lesson 68 - Styracosaurus
Styracosaurus (meaning "spiked lizard") was a genus of herbivorous ceratopsian dinosaur from the Cretaceous Period (Campanian stage), about 76.5 to 75.0 million years ago. It had four to six long horns extending from its neck frill, a smaller horn on each of its cheeks, and a single horn protruding from its nose, which may have been up to 60 centimetres (2 ft) long and 15 centimetres (6 in) wide. The function or functions of the horns and frills have been debated for many years.
Styracosaurus was a relatively large dinosaur, reaching lengths of 5.5 metres (18 ft) and weighing nearly 3 tons. It stood about 1.8 meters (6 ft) tall. Styracosaurus possessed four short legs and a bulky body. Its tail was rather short. The skull had a beak and shearing cheek teeth arranged in continuous dental batteries, suggesting that the animal sliced up plants. Like other ceratopsians, this dinosaur may have been a herd animal, traveling in large groups, as suggested by bonebeds.
Named by Lawrence Lambe in 1913, Styracosaurus is a member of the Centrosaurinae. One species, S. albertensis, is currently assigned to Styracosaurus. Other species assigned to the genus have since been reassigned elsewhere.
Length: 18 feet
Height: 6 feet
Weight: 6,000 lbs
Date Range: 76.5 - 75 Ma, Campanian Age, Late Cretaceous Period
|Caption (Picture Source)|
The skull was massive, with a large nostril, a tall straight nose horn, and a parietosquasomal frill (a neck frill) crowned with at least four large spikes. Each of the four
Aside from the large nasal horn and four long frill spikes, the cranial ornamentation was variable. Some individuals had small hook-like projections and knobs at the posterior margin of the frill, similar to but smaller than those in Centrosaurus. Others had less prominent tabs. Some, like the type individual, had a third pair of long frill spikes. Others had much smaller projections, and small points are found on the side margins of some but not all specimens. Modest pyramid-shaped brow horns were present in subadults, but were replaced by pits in adults. Like most ceratopsids, Styracosaurus had large fenestrae (skull openings) in its frill. The front of the mouth had a toothless beak.
The bulky body of Styracosaurus resembled that of a rhinoceros. It had powerful shoulders which may have been useful in intraspecies combat. Styracosaurus had a relatively short tail. Each toe bore a hooflike ungual which was sheathed in horn.
Various limb positions have been proposed for Styracosaurus and ceratopsids in general, including forelegs which were held underneath the body, or, alternatively, held in a sprawling position. The most recent work has put forward an intermediate crouched position as most likely. Paleontologists Gregory Paul and Per Christiansen of the Zoological Museum of the University of Copenhagen in Denmark proposed that large ceratopsians such as Styracosaurus were able to run faster than an elephant, based on possible ceratopsian trackways which did not exhibit signs of sprawling forelimbs.
Styracosaurus is a member of the Centrosaurinae, a subfamily of large North American horned dinosaurs characterized by their "prominent nasal horns, subordinate brow horns, short squamosals in a short frill, a tall, deep face relative to the ceratopines, and a projection into the rear of the nasal fenestra." Other members of the clade include Centrosaurus (from which the group takes its name), Pachyrhinosaurus, Avaceratops, Einiosaurus, Albertaceratops, Achelousaurus, Brachyceratops, and Monoclonius, although these last two are dubious. Because of the variation between species and even individual specimens of centrosaurines, there has been much debate over which genera and species are valid, particularly whether Centrosaurus and/or Monoclonius are valid genera, undiagnosable, or possibly members of the opposite sex. In 1996, Peter Dodson found enough variation between Centrosaurus, Styracosaurus, and Monoclonius to warrant separate genera, and that Styracosaurus resembled Centrosaurus more closely than either resembled Monoclonius. Dodson also believed one species of Monoclonius, M. nasicornis, may actually have been a female Styracosaurus. His assessments have been partially followed, with other researchers not accepting Monoclonius nasicornis as a female Styracosaurus, or Monoclonius as a valid genus. While sexual dimorphism has been proposed for an earlier ceratopsian, Protoceratops, there is no firm evidence for sexual dimorphism in any ceratopsid.
The evolutionary origins of Styracosaurus were not understood for many years because fossil evidence for early ceratopsians was sparse. The discovery of Protoceratops, in 1922, shed light on early ceratopsid relationships, but several decades passed before additional finds filled in more of the blanks. Fresh discoveries in the late 1990s and 2000s, including Zuniceratops, the earliest known ceratopsian with brow horns, and Yinlong, the first known Jurassic ceratopsian, indicate what the ancestors of Styracosaurus may have looked like. These new discoveries have been important in illuminating the origins of horned dinosaurs in general, and suggest that the group originated during the Jurassic in Asia, with the appearance of true horned ceratopsians occurring by the beginning of the late Cretaceous in North America.
Discoveries and species
The first fossil remains of Styracosaurus were collected in Alberta, Canada by C.M. Sternberg (from an area now known as Dinosaur Provincial Park, in a formation now called the Dinosaur Park Formation) and named by Lawrence Lambe in 1913. This quarry was revisited in 1935 by a Royal Ontario Museum crew who found the missing lower jaws and most of the skeleton. These fossils indicate that S. albertensis was around 5.5 to 5.8 meters in length and stood about 1.65 meters high at the hips. An unusual feature of this first skull is that the smallest frill spike on the left side is partially overlapped at its base by the next spike. It appears that the frill suffered a break at this point in life and was shortened by about 6 centimeters (2 in). The normal shape of this area is unknown because the corresponding area of the right side of the frill was not recovered.
Barnum Brown and crew, working for the American Museum of Natural History in New York, collected a nearly complete articulated skeleton with a partial skull in 1915. These fossils were also found in the Dinosaur Park Formation, near Steveville, Alberta. Brown and Erich Maren Schlaikjer compared the finds, and, though they allowed that both specimens were from the same general locality and geological formation, they considered the specimen sufficiently distinct from the holotype to warrant a new species, and
In the summer of 2006, Darren Tanke of the Royal Tyrrell Museum of Palaeontology in Drumheller, Alberta relocated the long lost S. parksi site. Pieces of the skull, evidently abandoned by the 1915 crew, were found in the quarry. These were collected and it is hoped more pieces will be found, perhaps enough to warrant a redescription of the skull and test whether S. albertensis and S. parksi are the same. The Tyrrell Museum has also collected several partial Styracosaurus skulls. At least one confirmed bonebed (bonebed 42) in Dinosaur Provincial Park has also been explored (other proposed Styracosaurus bonebeds instead have fossils from a mix of animals, and nondiagnostic ceratopsian remains). Bonebed 42 is known to contain numerous pieces of skulls such as horncores, jaws and frill pieces.
A third species, S. ovatus, from the Two Medicine Formation of Montana, was described by Gilmore in 1930. The fossil material is limited, with the best being a portion of the parietal bone of the frill, but one unusual feature is that the pair of spikes closest to the midline converge towards the midline, rather than away from it as in S. albertensis. There also may only have been two sets of spikes on each side of the frill, instead of three. The spikes are much shorter than in S. albertensis, with the longest only 295 millimeters (11.6 in) long. A 2010 review of styracosaur skull remains by Ryan, Holmes, and Russell found it to be a distinct species, and in 2010 McDonald and Horner placed it in its own genus, Rubeosaurus.
Styracosaurus and other horned dinosaurs are often depicted in popular culture as herd animals. A bonebed composed of Styracosaurus remains is known from the Dinosaur Park Formation of Alberta, about halfway up the formation. This bonebed is associated with different types of river deposits. The mass deaths may have been a result of otherwise non-herding animals congregating around a waterhole in a period of drought, with evidence suggesting the environment may have been seasonal and semiarid. Styracosaurus is known from a higher position in the formation (relating specifically to its own genus) than the closely related Centrosaurus, suggesting that Styracosaurus displaced Centrosaurus as the environment changed over time and/or dimension.
Dentition and diet
Styracosaurs were herbivorous dinosaurs; they probably fed mostly on low growth because of the position of the head. They may, however, have been able to knock down taller plants with their horns, beak, and bulk. The jaws were tipped with a deep, narrow beak, believed to have been better at grasping and plucking than biting.
Ceratopsid teeth, including those of Styracosaurus, were arranged in groups called batteries. Older teeth on top were continually replaced by the teeth underneath them. Unlike hadrosaurids, which also had dental batteries, ceratopsid teeth sliced but did not grind. Some scientists have suggested that ceratopsids like Styracosaurus ate palms and cycads, while others have suggested ferns. Dodson has proposed that Late Cretaceous ceratopsians may have knocked down angiosperm trees and then sheared off leaves and twigs.
Horns and frill
The large nasal horns and frills of Styracosaurus are among the most distinctive facial adornments of all dinosaurs. Their function has been the subject of debate since the first
Early in the 20th century, paleontologist R. S. Lull proposed that the frills of ceratopsian dinosaurs acted as anchor points for their jaw muscles. He later noted that for Styracosaurus, the spikes would have given it a formidable appearance. In 1996, Dodson supported the idea of muscle attachments in part and created detailed diagrams of possible muscle attachments in the frills of Styracosaurus and Chasmosaurus, but did not subscribe to the idea that they completely filled in the fenestrae. C.A. Forster, however, found no evidence of large muscle attachments on the frill bones.
It was long believed that ceratopsians like Styracosaurus used their frills and horns in defense against the large predatory dinosaurs of the time. Although pitting, holes, lesions, and other damage on ceratopsid skulls are often attributed to horn damage in combat, a 2006 study found no evidence for horn thrust injuries causing these forms of damage (for example, there is no evidence of infection or healing). Instead, non-pathological bone resorption, or unknown bone diseases, are suggested as causes.
However, a newer study compared incidence rates of skull lesions in Triceratops and Centrosaurus and showed that these were consistent with Triceratops using its horns in combat and the frill being adapted as a protective structure, while lower pathology rates in Centrosaurus may indicate visual rather than physical use of cranial ornamentation, or a form of combat focused on the body rather than the head; as Centrosaurus was more closely related to Styracosaurus and both genera had long nasal horns, the results for this genus would be more applicable for Styracosaurus. The researchers also concluded that the damage found on the specimens in the study was often too localized to be caused by bone disease.
The large frill on Styracosaurus and related genera also may have helped to increase body area to regulate body temperature, like the ears of the modern elephant. A similar theory has been proposed regarding the plates of Stegosaurus, although this use alone would not account for the bizarre and extravagant variation seen in different members of the Ceratopsidae. This observation is highly suggestive of what is now believed to be the primary function, display.
The theory of frill use in sexual display was first proposed in 1961 by Davitashvili. This theory has gained increasing acceptance. Evidence that visual display was important, either in courtship or in other social behavior, can be seen in the fact that horned dinosaurs differ markedly in their adornments, making each species highly distinctive. Also, modern living creatures with such displays of horns and adornments use them in similar behavior.
In popular culture
Because of the distinctive frill and horns of Styracosaurus, depictions of these animals are
On the small screen, Styracosaurus has appeared in many cartoons and anime, including Power Rangers: Dino Thunder (Bakuryuu Sentai Abaranger), Dinosaur King, Dinozaurs, "Dinosquad"Dino-Riders, Dinosaucers, and Zoids. Styracosaurus has also been featured in various video games, including the popular Jurassic Park, Turok, Zoo Tycoon, and Banjo-Kazooie game franchises.
